Applications Information
3.1
434 MHz Application
This application was designed to provide typical NF = 1.65 dB, S21 gain = 20 dB, OIP3 =10.6 dBm at
434 MHz. Typical performance that can be expected from this circuit at 2.75 V is listed in Table 6 . The
component values can be changed to enhance the performance of a particular parameter, but usually at the
expense of another. Two values of bias resistor R1 are shown to demonstrate performance for different IP3
and Icc requirements.
? Values of external resistor R1 are varied to adjust Icc and IP3.
? Inductor L3 provides bias to the logic circuit.
Figure 7 is the 434 MHz application schematic with package pinouts and the circuit component topology.
V cc
L3
270 nH
C4
0.1
uF
C5
33 pF
Enable
5
4
L2
4 7 nH
R2
C3
Gain
6
Logic
3
30 ohm
2 2 pF
RF
OUT
R3
82 ohm
L1
27 nH
C2
47 pF
7
2
R1
1.2 kohm
Rbias
8
1
Emit
.
C1
1 .3 pF
Figure 7. 434 MHz Application Schematic
Table 6. Typical 434 MHz Evaluation Board Performance (Vcc = 2.75V, TA = 25 ° C)
Characteristic
Symbol
Min
Typ
Max
Unit
R1 = 1.2 k Ω
Frequency
f
—
434
—
MHz
RF Gain
High Gain
Bypass
G
19.3
-9.5
20.3
-8.5
—
—
dB
Output Third Order Intercept Point
High Gain
Bypass
OIP3
9.5
15.5
10.6
16.6
—
—
dBm
Input Third Order Intercept Point
High Gain
Bypass
Out Ref P1dB
High Gain
In Ref P1dB
High Gain
IIP3
P1dBout
P1dBin
-10.7
24
6.8
-13.5
-9.7
25.1
7.8
-12.5
—
—
—
—
dBm
dBm
dBm
MC13852 Advance Information, Rev. 2.0
Freescale Semiconductor
9
